Black Color Freezer Compressor , ZR36KC-PFV-522 Ac Scroll Compressor 3HP

Product Categories

Shenzhen Ruifujie Technology Co., Ltd.

Trust Seal

Verified Supplier

Credit Check

Supplier Assessment

Contact Now

Voltage : 208v-230v/60hz

Type : Compressor

Currency A : 15.9

Model Number : ZR36KC-PFV-522

weight (kg) : 27.2

Warranty : 1 Year

Certification : CE

Place of Origin : China

MOQ : 1

Price : discussed

Payment Terms : T/T

Supply Ability : 5,000pcs per month

Delivery Time : 7-10 working days after receiving payment

Packaging Details : Wooden case or 12 units in one pallet

EER btu/wh : 11.0

BTU/H : 36900

mode : ZR36KC-PFV-522

Horse Power(hp) : 3.0

Contact Now

Black Color Freezer Compressor, ZR36KC-PFV-522 AC Scroll Compressor 3HP

ZR36 hermetic compressor ZR36KC-PFV-522 scroll compressor ZR36KC

Product Specifications

Features

ZR series scroll compressor can be used for air conditioning and refrigeration.
Refrigerant: R22 Volt/HZ: 220/380V 50/60 Hz

Nature of Compressor

Technical Data - Model Series 1

Model	Horsepower (HP)	Refrigerating Capacity (W)	Input Power (W)	Electricity (A)	Displacement (cc/Rev.)	Oil Capacity (L)	Net Weight (KG)	Locked-Rotor Current (A)	Noise Power
ZR26KM	2.2	6250	1970	9.9	34.6	0.77	19.6	53	63
ZR38KM	2.3	6750	2020	9.2	37.2	0.77	19.4	52.9	63.0
ZR30KM	2.5	7350	2190	10.1	40.5	0.77	19.3	52.9	63.0
ZR32KS	2.7	7900	2410	10.9	44.3	0.74	22.1	66.0	68.0
ZR34KH	2.8	8200	2520	13.6	46.2	1.04	30.4	100.0	66.0
ZR36KH	3.0	8900	2730	13.6	49.5	1.24	30.4	100.0	68.0
ZR39KH	3.3	9850	3000	14.6	54.2	1.24	30.4	114.0	68.0
ZR42K3	3.5	10250	3150	15.2	57.2	1.24	30.4	97.0	68.0
ZR45K3	3.8	11200	3380	16.4	61.1	1.24	32.2	114.0	68.0
ZR47K3	3.9	11550	3460	16.8	63.3	1.24	31.3	114.0	68.0
ZR48K3	4.0	11850	3630	17.6	65.5	1.24	31.3	114.0	68.0
ZR61KC	5.1	14950	4550	21.7	82.6	1.66	42.6	150.0	71.0
ZR68KC	5.7	16700	5130	24.5	93.0	1.83	40.4	150.0	72.0

Technical Data - Model Series 2

Model	Horsepower (HP)	Refrigerating Capacity (W)	Input Power (W)	Electricity (A)	Displacement (cc/Rev.)	Oil Capacity (L)	Net Weight (KG)	Locked-Rotor Current (A)	Noise Power
ZR28KM	2.3	8250	2450	10.9	37.2	0.77	19.4	61.5	66
ZR28KC	2.3	8500	2620	12.0	39.3	1.12	26.7	73.0	68.0
ZR32K3	2.7	9550	2960	13.6	43.4	1.24	28.7	83.0	71
ZR34KC	2.8	10050	3120	14.6	46.2	1.24	28.5	93.0	71.0
ZR36KC	3.0	10800	3350	15.9	49.5	1.24	27.2	100.0	71.0
ZR42KC	3.5	12300	3820	19.7	57.2	1.24	28.1	127	71.0
ZR45KC	3.8	13500	4140	20.9	61.1	1.24	30.4	131.0	71.0
ZR48KC	4.0	14600	4330	19.5	65.6	1.24	32.2	137.0	71.0
ZR54KC	4.5	16100	4830	21.4	73.2	1.66	43.1	148.0	74.0
ZR57KC	4.8	17000	5040	23.6	77.2	1.66	40.8	148.0	74.0
ZR61KC	5.1	18200	5500	25.4	82.6	1.66	39.5	14.0	74.0
ZR68KC	5.7	20400	6200	28.0	93.0	1.77	40.4	176.0	74.0
